M-1008

M Series Professional Power Amplifiers Low Noise: Microsecond-level shutdown of pre-stage input noise, static operation without noise interference. Smooth music playbac comfortable for indoor use. Excellent Sound Quality: Deep and solid bass, sweet and clear midrange, delicate treble. Effortless karaoke, room entertainment that isand pleasant to listen to. High Efficiency: High overall efficiency, low-temperature operation, energy-saving, and eco-friendly. Soft Protection: Continuous output even under low impedance or overheatin conditions, allowing for uninterrupted entertainment. Stable performance and reliable operation. Compact Size: 2U chassis with short depth, easy to install in cabinets, and space-saving. Aesthetiructure: Symmetrical left and right channel internal design, rational and grand, with exquisite craftsmanship. Aluminum front panel, high-end and beautiful.
  • 产品介绍

  • 产品规格

M系列专业功率放大器 静噪低:前级输入噪声微秒级关断,静态无噪声干扰。音乐流畅,室内使用安静舒适。
音质佳:低频深沉厚实,中音甜美嘹亮,高音纤细。轻松K歌,房间娱乐耐久动听。
效率高:整机高效率达输出,低温工作、节能省电、低碳环保。
软保护:低阻、过热工作,不断输出,尽情娱乐。性能稳定,运行可靠。
体积小:2U机身,深度短,易于柜内安放,节省放置空间。
结构美:内部设计左右声道对称,合理大气,制作精细。铝制面板,高档美观
输入/输出通道数:2
额定输出功率:EIA测试标准,输入电压AC230V,1KHz,最大谐波失真1%,单声道测试
8Ω负载:2×1000W
4Ω负载:2×1600W
输入灵敏度:0dB(0.775Vrms)/1.4V/26dB
频率响应:20-2KHz(±0.3dB)
输入阻抗:20KΩ(平衡/立体声 ) 10KΩ(不平衡/并联)
转换速率:≥30V/us
阻尼系数:DH10、DH16≥400 DH30、DH40、DH50≥600
通道隔离:>70dB@1KHz
信噪比:>100dB
总谐波失真:<0.1%1KHz 8Ω@1W
互调失真:<0.2%, 8Ω@1W
尺寸(mm):482×132×407 mm
重量(净重):33 kg
